Cylindrical Li-ion Batteries contains much higher energy density. Typical applications are for camcorders, notebooks, torches and power banks.
Cells
| Model | Nominal Voltage(V) | Nominal Capacity(mAh) | Energy(Wh) | Rated Charge Current(mA) | Rated Discharge Current(mA) | Max Discharge Current(mA) | Charging Voltage(V) | Charging Cut-off Voltage(V) | Internal Rensistance(MΩ) | Max Diameter(mm) | Max Height(mm) | Approx.Weight(g) |
| ICR14400 | 3.7 | 600 | 2.2 | 120 | 120 | 600 | 4.2 | 2.75 | 80 | 14.25 | 39.5 | 15.5 |
| ICR14430 | 3.7 | 650 | 2.4 | 130 | 130 | 650 | 4.2 | 2.75 | 80 | 14.3 | 43 | 14.0 |
| ICR14430 | 3.7 | 700 | 2.5 | 140 | 140 | 700 | 4.2 | 2.75 | 80 | 14.3 | 43 | 16.8 |
| ICR14500 | 3.7 | 700 | 2.5 | 140 | 140 | 700 | 4.2 | 2.75 | 80 | 14.3 | 49 | 16.0 |
| ICR14500 | 3.7 | 850 | 3.1 | 170 | 170 | 850 | 4.2 | 2.75 | 80 | 14.3 | 49 | 18.0 |
| ICR18490 | 3.7 | 1300 | 4.8 | 260 | 260 | 1300 | 4.2 | 2.75 | 80 | 18.52 | 49 | 31.0 |
| ICR18490 | 3.7 | 1600 | 5.9 | 320 | 320 | 1600 | 4.2 | 2.75 | 80 | 18.5 | 49 | 33.0 |
| ICR18490 | 3.7 | 1900 | 7.0 | 380 | 380 | 1900 | 4.2 | 2.75 | 70 | 18.5 | 49 | 36.0 |
| ICR18650 | 3.7 | 2000 | 7.4 | 400 | 400 | 2000 | 4.2 | 2.75 | 60 | 18.25 | 65 | 45.0 |
| ICR18650 | 3.7 | 2200 | 8.1 | 440 | 440 | 2200 | 4.2 | 2.75 | 60 | 18.25 | 65 | 47.0 |
| ICR18650 | 3.7 | 2600 | 9.6 | 520 | 520 | 2600 | 4.2 | 2.75 | 60 | 18.25 | 65 | 57.0 |
| ICR26650 | 3.7 | 4500 | 18.5 | 1000 | 1000 | 500 | 4.2 | 2.75 | 60 | 26.25 | 66.5 | 9430 |
Features
• Lithium-Nickel-Cobalt-Manganese(NCM) Chemistry • Certified high quality meets international safety standard such as EN62133 and UL.
• High energy density • High drain discharging or special discharging requirements are also available.
Characteristics
• Typical cell : 14500, 18650, 26650 • Voltage : 3.7V• Capacity : 700mAh ~ 5Ah• Output : 2.5Wh ~ 18.5Wh
Ready for Battery Pack Assembly
• Cell Models Variety Available • Multiple cells assembled with Protection Circuit Board (PCB), Wire & Connector Available
• Battery Modules or Units Available for Variety Applications
Replacement
• Plug & play replacement in Battery Pack Level for maintenance
Applications
The battery is applicable for industrial, consumer purposes. Multiple cells are connected for different high power applications such as,
• Electric Power Tools • Scooter Vehicles • Medical • Telecom • Robotic • Torch • Toys
